Data Sheet
Hyundai NEXO
Fuel Cell SUV.
A fuel cell SUV represented in New Zealand by a small evaluation fleet.
This data sheet models the NEXO generation already present in New Zealand. It stores 6.33 kg of hydrogen at 700 bar and has a published WLTP consumption of 0.95 kg/100 km and range of up to 666 km.
Hyundai's all-new NEXO is launching internationally in 2026 with 6.69 kg of hydrogen and a projected range of up to 826 km WLTP. It should become a separate calculator profile if New Zealand availability is confirmed.
Specifications from the all-new model are not mixed into the current New Zealand vehicle profile.
Specification
Comparable Fleet-Planning Data | |||
|---|---|---|---|
| Vehicle class | Passenger SUV | New Zealand status | Small evaluation fleet |
| Calculator status | Ready — published test-cycle default | Default hydrogen use | 0.95 kg/100 km |
| Hydrogen-use basis | Published WLTP combined consumption | Data confidence | Comparable laboratory result; verify against route use |
| Usable hydrogen | 6.33 kg | Storage pressure | 700 bar |
| Published range | Up to 666 km | Range basis | WLTP combined cycle |
| Refuelling time | Approximately 3–5 minutes | Tailpipe emissions | Water and water vapour |
Powertrain and Vehicle | |||
| Fuel cell output | 95 kW | Battery capacity | 1.56 kWh |
| Motor output | 120 kW | Maximum motor torque | 395 Nm |
| Hydrogen tanks | 3 | Passenger capacity | 5 |
| Kerb mass | Approximately 1,948 kg | Towing | Not permitted for this generation |
Calculator Inputs Supplied by the User | |||
| Vehicle quantity | User input | Distance per vehicle | User input in km/day or km/week |
| Operating days | User input | Fleet reserve | User input; applied separately |
Future Model
The All-New NEXO
Hyundai's 2026 model increases usable hydrogen to 6.69 kg, fuel cell stack output to 110 kW gross, motor output to 150 kW and projected WLTP range to 826 km. Hyundai also specifies approximately five-minute refuelling.
The future model is not yet used as a New Zealand calculator default.
Other Links
Evidence and Notes
Using This Profile
Use a separate profile for each NEXO generation. Mixing the earlier vehicle's measured use with the new vehicle's larger tank and longer range would create an invalid fleet estimate.
Source data checked 17 September 2026.
