Data Sheet
GBV / TR Group
Fuel Cell Tractor.
A New Zealand-integrated 50-tonne fuel cell tractor offered through maintained lease and rental.
GBV integrates Toyota fuel cells, hydrogen storage, a battery, controls and an electric drivetrain into a DAF CF 85 6×4 tractor platform. TR Group publishes a 450–500 km range with 52 kg of onboard hydrogen.
The calculator default uses the lower end of the range, producing a conservative range-derived consumption of 11.56 kg/100 km.
The storage pressure and refuelling time have not been stated in the current public TR Group brochure and are therefore not assumed here.
Specification
Comparable Fleet-Planning Data | |||
|---|---|---|---|
| Vehicle class | Heavy tractor unit | New Zealand status | Commercial lease and rental |
| Calculator status | Ready — conservative range-derived default | Default hydrogen use | 11.56 kg/100 km |
| Hydrogen-use basis | 52 kg ÷ minimum 450 km range | Data confidence | Indicative; replace with route data where available |
| Usable hydrogen | Approximately 52 kg | Storage pressure | Not published |
| Published range | 450–500 km | Range basis | TR Group indicative guide |
| Refuelling time | Not published | Tailpipe emissions | Water and water vapour |
Powertrain and Vehicle | |||
| Fuel cell output | 170 kW (2 × Toyota 85 kW) | Battery capacity | 124 kWh |
| Motor output | 350 kW | Maximum motor torque | 2,500 Nm |
| Gross combination mass | 50,000 kg | Tractor tare | 11,440 kg |
| Base platform | DAF CF 85 6×4 | Transmission | 6-speed |
Calculator Inputs Supplied by the User | |||
| Vehicle quantity | User input | Distance per vehicle | User input in km/day or km/week |
| Operating days | User input | Fleet reserve | User input; applied separately |
Evidence and Notes
Using This Profile
The published brochure states that its figures are indicative. Payload, trailer configuration, route and actual operating mass should be recorded in any project model.
Source data checked 17 September 2026.
